The 4000W MPPT inverter allows the direct use of photovoltaic panel systems to power resistance heating devices such as electric boilers, heaters, heating mats, water heating, etc.
The inverter is also equipped with an AC input that allows the inverter to be connected to the mains voltage and heat water even when solar radiation is insufficient for heating.
The system is simple, it only requires the connection of the appropriate number of photovoltaic panels with a maximum power of 4000W with an operating voltage of 160 ~ 350V DC, a mains voltage of 230C AC, and a connection to a resistive load, e.g. a heating coil, an electric boiler, an electric radiator or floor heating.
The direct current generated in the panels, which cannot be fed directly to the heating devices, is converted into alternating current in the inverter, which can be used to power the heating devices.
The inverter has a priority input from the photovoltaic panels and if this voltage drops below 120V, the water heating will be supplied from the 230V AC mains voltage.
It is equipped with an LED panel that informs the user about the current status of the inverter: indication of water heating from PV panels, indication of water heating from the 230V AC mains, indication of operation, indication of fault status.
Technical parameters:
PV panel connection: series or series-parallel.
Priority input: PV panels.
Backup input: mains 230V AC.
Operating temperature: -25 °C ~ + 55 °C.
Efficiency: > 99%.
Cooling: passive.
Input short circuit protection.
Overheating protection.
PV panel input connection: MC4 connectors.
Panels and boiler are not included.
Please note that installation and dismantling of solar panels and solar accessories must be carried out by a qualified person.
